| General Info |
| Device Type |
Motherboard. |
| Brand |
GIGABYTE. |
| Device Model |
MB GIGABYTE Z790M EAGLE AX. |
| Color |
Black. |
| Technical Spec |
| CPU |
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors, L3 cache varies with CPU. |
| Chipset |
Intel® Z790 Express Chipset. |
| Memory |
Support for DDR5. |
| Graphics |
Integrated Graphics Processor-Intel® HD Graphics support. |
| Expansion Slots |
CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16), Chipset: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4), 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4), 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3). |
| Storage |
CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU), Chipset: 1 x M.2 connectors (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB), 1 x M.2 connectors (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB), 4 x SATA 6Gb/s connectors. |
| USB |
Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support, 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header, 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel, 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header), 2 x USB 2.0/1.1 ports on the back panel. |
| Form Factor |
ATX Form Factor; 30.5cm x 24.4cm. |
| Operating System |
Support for Windows 11 64-bit, Support for Windows 10 64-bit. |
| BIOS |
1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. |
