The MSI PRO X870E-P WIFI is an ATX motherboard built on the AMD X870E chipset for Ryzen 9000, 8000 and 7000 desktop processors in the AM5 socket. It offers 4 x DDR5 slots up to 8200 MT/s (OC), PCIe 5.0 x16, 3 x M.2 sockets, USB4 (40Gbps), Wi-Fi 7 and 5G LAN.
Key Features
AM5 socket for AMD Ryzen 9000, 8000 and 7000 Series desktop processors
AMD X870E chipset with a 14+2+1 DRPS power design
4 x DDR5 UDIMM slots, up to 256GB, 8200 MT/s (OC)
PCIe 5.0 x16 slot and PCIe 5.0 M.2 with EZ M.2 Shield Frozr II (7W/mK thermal pads)
3 x M.2 sockets and 4 x SATA 6Gb/s
USB4 up to 40Gbps with DisplayPort output via Type-C
Wi-Fi 7 and Bluetooth 5.4
Realtek 8126VB 5G LAN
Realtek ALC897 7.1-channel audio with Audio Boost, BIOS Flash and Clear CMOS buttons
Full Specifications
General
Brand
MSI
Model
PRO X870E-P WIFI
Part Number
911-7E70-014
Form Factor
ATX (243.84mm x 304.8mm)
Color
Black
CPU and Chipset
Socket
AM5
Supported CPUs
AMD Ryzen 9000, 8000 and 7000 Series desktop processors
Chipset
AMD X870E
Power Design
14+2+1 DRPS
Memory
Type / Slots
DDR5 UDIMM, 4 slots, dual channel
Maximum Capacity
256GB
Speed
5600-4800 MT/s (JEDEC), 8200-5600 MT/s (OC)
Expansion and Storage
PCIe x16
3 x PCIe x16 slots; primary slot PCIe 5.0 x16
PCIe x1
1 x PCIe x1 slot
M.2
3 x M.2 (top slot PCIe 5.0 x4; two PCIe 4.0 x4)
SATA
4 x SATA 6Gb/s
RAID
SATA: RAID 0/1/10; NVMe: RAID 0/1/5
Networking and Audio
LAN
Realtek 8126VB 5G LAN
Wi-Fi
Wi-Fi 7, 2.4/5/6GHz, MU-MIMO TX/RX
Bluetooth
Bluetooth 5.4
Audio
Realtek ALC897 7.1-channel HD Audio
Ports and Connectors
Rear USB
USB 2.0, 5Gbps, 10Gbps and 40Gbps (USB4) Type-C
Video Output
HDMI 2.1 and DisplayPort via USB4 Type-C
Rear Buttons
BIOS Flash button, Clear CMOS button
Internal Connectors
24-pin ATX, dual CPU power, PCIe power, fan headers, RGB headers, TPM 2.0 header
Who Is It For?
High-end Ryzen 9000/7000 gaming and workstation builds
Users who want USB4 and Wi-Fi 7 on AM5
Builders needing PCIe 5.0 graphics and M.2 storage
Creators using fast external USB4 storage
In the Box
MSI PRO X870E-P WIFI motherboard
Contents as supplied by MSI (typically SATA cables, Wi-Fi antenna, quick guide)
Frequently Asked Questions
Does it support USB4? Yes, a 40Gbps USB4 Type-C port with DisplayPort output.
Which CPUs does it support? AMD Ryzen 9000, 8000 and 7000 Series desktop processors on the AM5 socket.
Does it have Wi-Fi? Yes, Wi-Fi 7 with Bluetooth 5.4.
Order the MSI PRO X870E-P WIFI Motherboard from PC PARK with warranty and fast delivery across Saudi Arabia.
