The NZXT H6 Flow RGB is a compact dual chamber mid tower with a wrap-around panoramic tempered glass front and side. Three angled F120 RGB Core fans push air straight toward the GPU, while the rear chamber hides the PSU and cables. It supports ATX boards, 365mm graphics cards and a 360mm radiator at the top.
Key Features
Compact dual chamber design with 91mm of cable routing space
Panoramic ultra-clear tempered glass front and side panels
3x F120 RGB Core fans angled toward the GPU for direct cooling
Top radiator support up to 360mm, rear up to 120mm
Fits 365mm GPUs, 163mm CPU coolers and 200mm PSUs
Room for up to 9 fans including 2x 140mm on the bottom
Tool-free access to the top and side panels
Front I/O with USB 3.2 Type-C and 2x USB-A
Full Specifications
General
Brand
NZXT
Model
H6 Flow RGB
Part Number
CC-H61FW-R1
Case Type
Mid Tower, compact dual chamber
Colour
White
Materials
SGCC steel, ultra-clear tempered glass
Side Panel
Panoramic tempered glass (front and side)
Motherboard & Expansion
Motherboard Support
ATX / Micro-ATX / Mini-ITX
Back-Connector Motherboards
Not supported
Expansion Slots
7
Storage
2.5" Drive Bays
2
3.5" Drive Bays
1
Cooling
Pre-installed Fans
3 x F120 RGB Core (Case Version), angled front-right
Fan Speed
1,300 ± 130 RPM
Airflow
55.17 CFM
Static Pressure
1.27 mm-H2O
Noise Level
26.1 dBA
Fan Connector
3-pin DC
Front-Right Fans
3 x 120 mm (3 included)
Top Fans
3 x 120 mm or 2 x 140 mm
Bottom Fans
2 x 140 mm
Rear Fans
1 x 120 mm
Dust Filters
High-performance mesh
Radiator Support
Top
Up to 360 mm (radiator + fan thickness 30 mm)
Rear
Up to 120 mm
Clearances
Max GPU Length
365 mm
Max CPU Cooler Height
163 mm
Max PSU Length
200 mm
PSU Type
ATX
Cable Routing Space
91 mm
Front I/O
Ports
2 x USB 3.2 Type-A, 1 x USB 3.2 Type-C, 1 x headset audio jack
Dimensions & Weight
Dimensions
435 x 287 x 415 mm (H x W x D)
Volume
51.8 L
Weight
9.4 kg
Warranty
Manufacturer Warranty
2 years
Who Is It For?
Gamers who want a compact glass showcase PC
Builders who prefer cables hidden in a rear chamber
Users with a 360mm AIO cooler
Anyone wanting RGB fans that cool the GPU directly
In the Box
NZXT H6 Flow RGB case (White)
3x F120 RGB Core fans (pre-installed)
Cable straps and installation hardware
Frequently Asked Questions
Does the NZXT H6 Flow RGB support back-connector motherboards? No. It supports standard ATX, Micro-ATX and Mini-ITX boards; back-connect boards are not supported.
What radiator can I install? Up to a 360mm radiator at the top (30mm radiator plus fan thickness limit) and 120mm at the rear.
How long a GPU fits? Graphics cards up to 365mm long are supported.
Order the NZXT H6 Flow RGB White from PC PARK with warranty and fast delivery across Saudi Arabia.
