| General |
| Brand |
Lenovo |
| Model |
Legion T5 26IRB8 |
| Part Number |
90UU00UPKS |
| Form Factor |
Tower (26 L) |
| Colour |
Storm Grey |
| Operating System |
Windows 11 Home |
| Processor |
| CPU |
Intel Core i9-14900F (14th Gen) |
| Cores / Threads |
24 cores (8P + 16E) / 32 threads |
| Base Clock |
P-core 2.0GHz / E-core 1.5GHz |
| Max Turbo |
Up to 5.8GHz |
| Cache |
36MB Intel Smart Cache |
| Chipset |
Intel B660 |
| Memory |
| Installed RAM |
32GB (2 x 16GB) DDR5-5600 UDIMM |
| Slots |
4x DDR5 UDIMM, dual-channel |
| Maximum Memory |
64GB |
| Storage |
| SSD |
1TB M.2 2280 PCIe 4.0 x4 NVMe |
| M.2 Slots |
2x M.2 SSD (one free) + 1x M.2 WLAN |
| Drive Bays |
1x 2.5-inch, 2x 3.5-inch |
| Optical Drive |
None |
| Graphics |
| GPU |
NVIDIA GeForce RTX 4070 Ti SUPER |
| Video Memory |
16GB GDDR6X |
| AI Performance |
706 AI TOPS (peak) |
| Video Outputs |
3x DisplayPort 1.4a, 1x HDMI 2.1a |
| Max Resolution |
7680 x 4320 @ 60Hz (DSC, HDR) |
| Displays Supported |
Up to 4 independent displays |
| Connectivity |
| Ethernet |
2.5GbE, Realtek RTL8125BG |
| Wi-Fi |
Wi-Fi 6E (802.11ax 2x2) |
| Bluetooth |
Bluetooth 5.3 |
| Ports |
| Front (Top) |
2x USB 3.2 Gen 1, 1x headphone (3.5mm), 1x microphone (3.5mm) |
| Rear |
1x USB-C 3.2 Gen 2 (data, 5V/3A), 2x USB 3.2 Gen 1, 4x USB 2.0, 1x RJ45, 3x audio jacks, lighting switch |
| Expansion |
| PCIe Slots |
1x PCIe 4.0 x16, 1x PCIe 3.0 x4 |
| Cooling & Lighting |
| CPU Cooler |
150W 120mm fan with ARGB |
| System Fans |
1x rear, 2x front, 2x top (all ARGB) |
| Heatsinks |
2x M.2 SSD, PCH and VRM heatsinks |
| Lighting |
Legion Lighting + internal ambient lighting |
| Audio |
| Audio Codec |
Realtek ALC897-Q HD Audio |
| Power & Security |
| Power Supply |
850W, 90% efficiency, 100-240V |
| Security |
Firmware TPM 2.0, BIOS and power-on passwords |
| Physical |
| Dimensions (W x D x H) |
205 x 396.9 x 425.9 mm |
| Weight |
Around 14 kg |
| Warranty |
| Warranty |
24 months |
